Description
Product description
- Conform to BS 4177 : 1992
- Front plate: white thermoset
- Supplied with optional faceplate screw caps
Technical recommendations
- Flush mounting back box: minimum 48mm deep
Installer advantages
- Terminal screws captive and backed off ready for cabling
Technical characteristics
| Type of switch | Off switch | Nominal voltage | 250 V |
| Type of socket outlet | British Standard | Nominal current socket outlet | 13 A |
| Number of socket outlets | 1 | Rated current | 13 A |
| Method of operation | Rocker/button | Device width | 146 mm |
| Mounting direction | Horizontal | Device height | 86 mm |
| Type of fastening | Mounting with screw | Device depth | 35 mm |
| With lighting | Yes | Compatible with Apple HomeKit | No |
| Mounting method | Flush-mounted | Compatible with Google Assistant | No |
| Material | Plastic | Compatible with Amazon Alexa | No |
| Material quality | Duroplast | IFTTT support available | No |
| Halogen free | Yes | Built-in depth | 22 mm |
| Surface protection | Untreated | Operating / setting temperature | -5-40 °C |
| Surface finishing | Glossy | Storage temperature | -5-40 °C |
| Colour | White | Voltage type | AC |
| RAL-number (similar) | 9003 | Antimicrobial treatment | No |
| Transparent | No | Connection type | Screwed terminal |
| Suitable for degree of protection (IP) | IP2X | Cable section | 10-10 mm² |
